Automotive Powertrain Manufacturing Technology and Know-how Automobile Division
TEST MEASURING EQUIPMENT
We have established a comprehensive quality inspection system using various equipment such as a 3D measuring machine, HYPOID GEAR measuring machine, HELICAL&SPUR GEAR tooth profile measuring machine, profile measuring machine, and thermal treatment inspection equipment. With these tools, we have strengthened our quality inspection processes to meet the highest standards and fulfill customer requirements with exceptional quality.
MEASURING INSTRUMENT
- 3-DIMENSIONAL MEASURING INSTRUMENT
- Merlin MAX 1100
- TOOTH MEASURING INSTRUMENT
- P65
- TOOTH MEASURING INSTRUMENT
- CLP-65
- PROFILE PROJECTOR
- PJ-3000
- ROUNDNESS MEASURING INSTRUMENT
- RONDCOM41C
- SHAPE MEASURING INSTRUMENT
- CV-250
- TOOTH MEASURING INSTRUMENT
- SIGMA3
- SURFACE ROUGHNESS MEASURING INSTRUMENT
- SJ-400
- TOOTH MEASURING INSTRUMENT
- 650 GMS
- DIGITAL ROCKWELL HARDNESS TESTER
- ARK-F3000
- METAL MICROSCOPE
- EPIPHOT 300U
- ROCKWELL HARDNESS TESTER
- SR-200
- BRINELL HARDNESS TESTER
- DTB-600N
- VICKERS HARDNESS TESTER
- HM-200
TEST EQUIPMENT
- DYNAMO TEST M/C
- SPECIAL PRODUCTION
- NVH TEST M/C
- SCXI-1000
- IDLE TESTER
- E-PLUS 3-PHASE INDUCTION MOTOR
- T260 LEAK TEST EQUIPMENT
- -
- OIL PUMP PERFORMANCE TESTER
- E-PLUS 3-PHASE INDUCTION MOTOR
- COMPREHENSIVE PERFORMANCE TESTER FOR INTERMEDIATE GEARBOX
- E-PLUS 3-PHASE INDUCTION MOTOR
- LEAK TEST M/C
- LEAK & OPERATION TEST
- UNLOADED TESTER VEHICLE (UTV)
- LOW-VOLTAGE 3-PHASE INDUCTION MOTOR
INSPECTION EQUIPMENT LIST
| No. | PHOTO | EQUIPMENT NAME | MODEL NAME | MANUFACTURER | QUANTITY | REMARKS |
|---|---|---|---|---|---|---|
| 1 | |
3-DIMENSIONAL MEASURING INSTRUMENT | MERLIN-1100 | IMS | 1 | 3-DIMENSIONAL MEASURING |
| 2 | |
TOOTH MEASURING INSTRUMENT | P65 | KLINGELNBERG | 1 | TOOTH MEASURING |
| 3 | |
TOOTH MEASURING INSTRUMENT | CLP-65 | OSAKA SEIMITSU KIKAI | 1 | TOOTH MEASURING |
| 4 | |
PROFILE PROJECTOR | PJ-3000 | Mitutoyo | 1 | SHAPE MEASUREMENT |
| 5 | |
ROUNDNESS MEASURING INSTRUMENT | RONDCOM41C | ACCRETECH | 1 | ROUNDNESS CYLINDER MEASUREMENT |
| 6 | |
SHAPE MEASURING INSTRUMENT | CV-250 | T&S GmbH | 1 | SHAPE MEASUREMENT |
| 7 | |
TOOTH MEASURING INSTRUMENT | SIGMA3 | GLEASON | 1 | TOOTH MEASURING |
| 8 | |
SURFACE ROUGHNESS GAUGE | SJ-400 | Mitutoyo | 1 | SURFACE ROUGHNESS MEASUREMENT |
| 9 | |
TOOTH MEASURING INSTRUMENT | 650 GMS | GLEASON | 1 | TOOTH MEASURING |
| 10 | |
DIGITAL ROCKWELL HARDNESS TESTER | ARK-F3000 | AKASHI | 1 | HARDNESS MEASUREMENT |
| 11 | |
METAL MICROSCOPE | EPIPHOT 300U | Nikon | 1 | MICROSTRUCTURE OBSERVATION |
| 12 | |
ROCKWELL HARDNESS TESTER | SR-200 | Samil Precision | 1 | HARDNESS MEASUREMENT |
| 13 | |
BRINELL HARDNESS TESTER | DTB-600N | Daekyung Tech | 1 | HARDNESS MEASUREMENT |
| 14 | |
VICKERS HARDNESS TESTER | HM-200 | Mitutoyo | 1 | HARDNESS MEASUREMENT |
| 15 | |
DYNAMO TEST M/C | SPECIAL PRODUCTION | YASKAWA | 1 | DURABILITY TESTING |
| 16 | |
NVH TEST M/C | SCXI-1000 | NATIONAL INSTRUMENTS | 1 | (NOISE AND VIBRATION MEASUREMENT |
| 17 | |
NO-LOAD TESTING M/C | E-PLUS 3-PHASE INDUCTION MOTOR | HYOSUNG | 1 | NO-LOAD OPERATION TEST |
| 18 | |
LEAK TEST M/C | SPECIAL PRODUCTION | Geumhyun Tech | 1 | LEAK & OPERATIONAL TESTING |
| 19 | |
OIL PUMP PERFORMANCE TESTER | E-PLUS 3-PHASE INDUCTION MOTOR | HYOSUNG | 1 | OPERATIONAL TESTING |
| 20 | |
COMPREHENSIVE PERFORMANCE TESTING MACHINE FOR INTERMEDIATE GEARBOX | SPECIAL PRODUCTION | Jinotech Co., Ltd. | 1 | PERFORMANCE TESTING |
| 21 | |
LEAK TEST M/C | SPECIAL PRODUCTION | CINCINNATI TEST SYSTEMS | 1 | LEAK TEST |
| 22 | |
UNLOADED TESTER VEHICLE (UTV) | LOW-VOLTAGE 3-PHASE INDUCTION MOTOR | Hyundai | 2 | NO-LOAD TESTING |
